6gm 1104 brushless motor

The 1104 brushless motor is a VERY SMALL 4300KV outrunner motor manufactured by Yinyan (China).  This is a popular high-speed motor meant for use with small propellers, 1S-2S power.   Its often used on small drones but can also be used on R/C model aircraft.

Similar in size to our 5gm brushless motor, but this one is less expensive. It can replace the brushed IPS motors that we used in our original 28" Rabid Models aircraft (for a big jump up in performance).

Specifications:

• Weight 6 gms
• Case size: 14.3mm diameter x 9mm deep
• 4300 KV
• Shaft size: 1.5mm
• Shaft length: 4.8mm
• 4-axis motor mount (uses M1.4 screws)
• 1-2 cell Lipo  (do not use with 3-cell)
• Power - 6-12 amps
• Rire length: 70mm
• Recommended prop:  2-inch 3 blade or 3-inch 2-blade

The package includes:  one 6gm 1104 brushless motor with mount. You will need bullet connectors, a prop adapter or prop saver (for 1.5mm shaft), and an 1S-2S ESC. We sell most of these items separately.   (here is the link to our ultra-small ESC)
